Liqin 200w Direct Burial IP67 Rated Transformer

(0)No Reviews yet
SKU: LIQ 200w Direct Burial Transformer

64 Available

Select Store to check availability.

Details

This is the most versatile little transformer that we've ever come across.  It can be buried, covered with a fake rock, mounted on wall, hid in the attic/crawlspace or simply left on the ground.  Plug it into a smart switch or use any type of outdoor rated timing device you'd like to control it!

  • 200w with15v output
  • Direct Burial - IP67 Rated
  • 25ft lead wire (12awg)
  • Plugs directly into 120V outlet
  • 5 year warranty

SPECIFICATION & FEATURES

  • Input: 120V+/-10%, 60Hz
  • Output: 12.5V 100W @8.33A / 300W @25A
  • Housing: Heavy duty high temperature fiber glass reinforced polypropylene
  • Long life, high temperature (200°F) Toroidal Copper transformer core
  • Completely potted for longer life, more efficiency and reduced noise
  • Recommend to use MIN 8% to Max 80% of the transformer capacity
MOUNTING TIPS
  •  The Transformer must connect To GFCI With Water Resistant protection.
  •  The GFCI mount of the transformer Must Meet NEC and Local Code
  •  A Water Proof Connector needs to be used on the Low Voltage Outputs.
  •  Recommend to mount the transformer in-ground or in a well-ventilated environment and avoid direct sunlight
  • to protect the housing aging. May be installed in wet or moist areas but not submerged
  •  Recommend to use on ambient temperature under 40°C(104°F).
  •  Use M5 or M6 screws with at least 30mm/1 1/4IN length to fix the transformer.
